GO OUT. MEET YOURSELF.

The KTM 690 RALLY is built for riders who go beyond the familiar. Designed for long-distance off-road travel and Rally Raid-inspired performance, it delivers the range, control, and capability to push deeper into the unknown.

Engine

Design

1-cylinder, 4-stroke engine

Displacement

692.7 cm³

Power

79 PS

Torque

73 Nm

Transmission

6-speed

CO2 emissions

99 g/km

Cooling

Liquid cooled

Engine cylinder

Single cylinder

EMS

Keihin EMS with RBW, twin ignition

Engine oil

Motorex Power Synth SAE 10W-50

Engine stroke

4-Stroke

Silencer

Stainless steel primary and secondary silencer

Chassis

Brake disc diameters (front/rear)

300 / 240 mm

Front brake disc diameter

300 mm

Front brake disc diameter

11.81 inch

Rear brake disc diameter

240 mm

Rear brake disc diameter

9.45 inch

Front brake

Brembo twin-piston floating calliper, brake disc

Rear brake

Brembo single-piston floating calliper, brake disc

Chain

520 X-Ring

Frame design

Chromium-Molybdenum steel trellis frame, powder coated

Steering head angle

62.3 °

Rear subframe design

Self-supporting plastic tank

Trail

121 mm

Wheelbase

1506 mm

Suspension

Front suspension

WP XPLOR-USD, Ø 48 mm

Rear suspension

WP XPLOR with Pro-Lever linkage

Suspension travel (front)

265 mm

Suspension travel (front)

10.43 inch

Suspension travel (rear)

Fehlende Variable inch

Front suspension addition

Compression, rebound

Rear suspension adjustment

Compression (high and low speed), rebound and preload adjustment

Dimensions

Seat height

935 mm

Wheelbase

1506 ± 15 mm

Tank capacity (approx.)

20 l

Ground clearance

265 mm

Weight (without fuel)

161.5 kg

Tank capacity (approx.)

5.28 US gal

Wheelbase tolerance

0.59 inch

Wheels

1.85 x 21"; 2.5 x 18"

Wheels

Spoked wheels with aluminium rims
