LEGENDARY ENDURO

The KTM 300 EXC maintains legendary status as the undisputed King of enduro. Not only does it have the most recognized title at the sharp end of hard enduro, it's still unmatched when it comes to 2-stroke ingenuity, fury, and downright fun. With a bulletproof, fuel-injected 2-stroke engine churning out masses of low-down torque and top-end fury, it's the ideal companion when tackling challenging terrain.

Engine

Design

1-cylinder, 2-stroke engine

Displacement

293.15 cm³

Transmission

6-speed

Fuel-mixture generation

Keihin EFI, throttle body 39 mm

EMS

Vitesco Technologies EMS

Clutch primary drive teeth

72

Primary drive

26:72

Clutch

Wet, DDS multi-disc clutch, Brembo hydraulics

Engine cylinder

Single cylinder

Engine stroke

2-Stroke

Chassis

Frame design

Central double-cradle-type 25CrMo4 steel

Front brake

Disc brake

Rear brake

Disc brake

Rear subframe design

Aluminum-reinforced polyamide

Chain

520 X-Ring

Suspension

Front suspension

WP XACT-USD, Ø 48 mm

Rear suspension

WP XPLOR shock absorber with PDS

Suspension travel (front)

300 mm

Suspension travel (rear)

310 mm

Front suspension adjustment

Compression and rebound adjustable

Rear suspension addition

Preload adjuster

Dimensions

Seat height

963 mm

Ground clearance

347 mm

Tank capacity (approx.)

9 l
