An icon that continues to evolve

Modernity and heritage interweave in a continuous dialogue, in the most technological Monster of all time. A bike designed down to the finest details, that retains the same spirit it had when it changed Ducati forever: simple, pure and immediately recognisable.

Type

Ducati V2 engine: 90° V2, 4 valves per cylinder, intake variable valves timing system, liquid cooled

Displacement

890 cc (54,3 cu in)

Bore x Stroke

96 mm x 61,5 mm (3,8 in x 2,4 in)

Compression Ratio

13,1:1

Power

111 hp (81,6 kW) @ 9.000 rpm

Torque

91,1 Nm (9,3 kgm, 67 lb ft) @ 7.250 rpm

Fuel Injection

Electronic fuel injection system. One injector per cylinder. Full ride-by-wire.

Exhaust

2-1-2 system

Gearbox

6 speed with Ducati Quick Shift up/down 2.0

Primary drive

Straight cut gears; Ratio 1.84:1

Ratio

1=38/14 2=34/17 3=32/20 4=29/22 5=24/21 6=26/25

Final drive

Chain 520; front sprocket 16; rear sprocket 42

Clutch

Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder

Frame

Monocoque Aluminium

Front suspension

Showa Ø 43 mm usd fork

Front Wheel

Casted light alloy, 3,50" x 17"

Front Tyre

Pirelli Diablo Rosso IV, 120/70 ZR17

Rear suspension

Showa monoshock with adjustable preload. Aluminium double-sided swingarm

Rear Wheel

Casted light alloy, 5,50” x 17”

Rear Tyre

Pirelli Diablo Rosso IV, 180/55 ZR17

Wheel Travel (Front/Rear)

130 mm / 145 mm (5,1 in / 5,7 in)

Front Brake

2 x Ø 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 4-piston calipers, radial master cylinder PR16/21. Cornering ABS.

Rear Brake

245 mm disc, 2-piston floating caliper. Cornering ABS

Instrumentation

Digital dashboard with 5'' full-colour TFT display, 800 x 480 px resolution; 16:9 ratio

Wet weight no fuel

175 kg (386 lb)

Seat Height

815 mm (32,1 in)
795 mm (31,3 in) with low seat accessory
775 mm (30,5 in) with low seat accessory + low suspension kit

Wheelbase

1.492 mm (58,7 in)

Rake

23,3°

Trail

92 mm (3,6 in)

Fuel Tank Capacity

14 l (3,7 US gal)

Number of Seats

2

Safety Equipment

Riding Modes, Power Modes, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Bosch Cornering ABS, Ducati Brake Light (DBL), Auto tyre calibration

Standard Equipment

Ducati Quick Shift (DQS) up/down 2.0, Coming Home, TFT colour display, Full LED lighting system, Daytime Running Light (DRL), Dynamic turn indicators, Self cancelling turn indicators, Lap Timer, Flyscreen, Passenger seat cover

Ready for

Anti-Theft, Tyre Pressure Monitoring System (TPMS), Cruise control, Ducati Multimedia System (DMS), Heated grips, Turn-by-Turn navigation system, USB port, Ducati Power Launch (DPL)
Availability of some accessories may vary. Please check with your dealer.

Warranty

24 months, unlimited mileage

Annual Service

12 months

Oil Service

15.000 km / 24 months

Valve Clearance Check

45.000 km

Emission notes

Only for countries where Euro 5+ standard applies

Notes

Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information
