Live. Play. Ride.

Climb aboard and let fun take charge. The new Hypermotard 698 Mono is the first single-cylinder road-going Supermotard by Ducati, born with just one aim – to transmit excitement, dominating the scene. Simple, lightweight, and agile, it is a true “fun-bike” with racing DNA.

Type

Superquadro Mono, single-cylinder, 4 valves per cylinder, Desmodromic timing, 2-balance countershafts, liquid cooled

Displacement

659 cc

Bore x Stroke

116 x 62.4 mm

Compression Ratio

13.1:1

Power

57 kW (77.5 hp) @ 9,750 rpm

Torque

63 Nm (46.5 lb-ft) @ 8,000 rpm

Fuel Injection

Electronic fuel injection system, Øe 62 mm throttle body with full Ride by Wire system

Exhaust

1-2 exhaust system, double aluminium mufflers, catalytic converter and lambda probe

Gearbox

6 speed with Ducati Quick Shift Up/Down

Primary drive

Straight cut gears; Ratio 1.968:1

Ratio

1=36/13 2=35/17 3=32/20 4=29/22 5=24/21 6=26/25

Final drive

Chain 520; Front sprocket 15; Rear sprocket 42

Clutch

Slipper and self-servo wet multiplate clutch, hydraulic control

Frame

Tubular steel Trellis frame

Front suspension

Ø 45 mm Marzocchi fully adjustable aluminium fork

Front Wheel

Y shaped 5-spoke light alloy 3.5" x 17"

Front Tyre

Pirelli Diablo Rosso IV, 120/70 ZR17

Rear suspension

Progressive linkage with Sachs fully adjustable monoshock. Aluminium double-sided swingarm

Rear Wheel

Y shaped 5-spoke light alloy 5.0" x 17"

Rear Tyre

Pirelli Diablo Rosso IV, 160/60 ZR17

Wheel Travel (Front/Rear)

215 mm (8.5 in) - 240 mm (9.4 in)

Front Brake

Ø 330 mm aluminium flange disc, Brembo M4.32 caliper, radial pump with adjustable lever, with Bosch Cornering ABS

Rear Brake

Ø 245 mm disc, single piston floating caliper, with Bosch Cornering ABS

Instrumentation

3.8" LCD display with Improved Black Nematic (IBN) technology

Wet weight no fuel

151 kg (333 lb)

Seat Height

904 mm (35.6 in)
889 mm (35.0 in) with low seat accessory
849 mm (33.4 in) with low seat + low suspension kit accessory

Wheelbase

1,443 mm (56.8 in)

Rake

26.1°

Trail

108 mm (4.2 in)

Fuel Tank Capacity

12 l (3 US gallons)

Number of Seats

2

Safety Equipment

Riding Modes, Bosch Cornering ABS, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Ducati Brake Light (DBL)

Standard Equipment

Power Modes, Ducati Power Launch (DPL), Ducati Quick Shift (DQS) Up/Down, Full LED lighting system, Daytime Running Lights (DRL), Tapered aluminium handlebars, Lithium-ion battery

Provided Equipment

Passenger footpegs

Ready for

Anti-theft system, Heated grips, Ducati Multimedia System (DMS).

Warranty

24 months unlimited mileage

Annual Service

12 months

Oil Service

15,000 km (9,000 miles) / 24 months

Valve Clearance Check

30,000 km (18,000 miles)
