Muscle-roadster with supersport personality

The V4 Granturismo takes center stage on our muscle bike and allows it to express its personality to the fullest. Ducati's four-cylinder engine guarantees high performance, combined with smoothness and regularity, at every rpm. The new chassis combines ideally with what have always been the Diavel's strengths, such as its characteristic riding position and comfort in medium-range touring. In addition, thanks to a major weight reduction, handling and agility improve noticeably.

Type

V4 Granturismo, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, Twin Pulse firing order, liquid cooled

Displacement

1,158 cc (71 cu in)

Bore x Stroke

83 mm x 53.5 mm

Compression Ratio

14.0:1

Power

168 hp (124 kW) @ 10,750 rpm

Torque

12.8 kgm (126 Nm, 93 lb ft) @ 7,500 rpm

Fuel Injection

Electronic fuel injection system, Øeq 46 mm elliptical throttle bodies with Ride-by-Wire system

Exhaust

Stainless steel exhaust muffler with 4 exit pipes

Gearbox

6 speed with Ducati Quick Shift up/down

Primary drive

Straight cut gears; Ratio 1.80:1

Ratio

1=40/13, 2=36/16, 3=34/19, 4=31/21, 5=29/23, 6=27/25

Final drive

Chain, front sprocket z16, rear sprocket z43

Clutch

Hydraulically controlled slipper and self-servo wet multiplate clutch

Frame

Aluminium monocoque frame

Front suspension

Ø 50 mm fully adjustable usd fork

Front Wheel

Light alloy cast, 3,5" x 17"

Front Tyre

Pirelli Diablo Rosso III, 120/70 ZR17

Rear suspension

Fully adjustable monoshock, aluminium single-sided swingarm

Rear Wheel

Light alloy cast, 8,0" x 17"

Rear Tyre

Pirelli Diablo Rosso III, 240/45 ZR17

Wheel Travel (Front/Rear)

120 mm / 145 mm (4.7 in / 5.7 in)

Front Brake

2 x Ø 330 mm semi-floating discs, radially mounted Brembo Stylema monobloc 4-piston calipers, radial master cylinder PR16/19, Cornering ABS

Rear Brake

Ø 265 mm disc, Brembo 2-piston floating caliper, Cornering ABS

Instrumentation

5" TFT colour display

Wet weight no fuel

223 kg (492 lb)

Seat Height

790 mm (31.1 in)

Wheelbase

1,593 mm (62.7 in)

Rake

26°

Trail

112 mm (4.4 in)

Fuel Tank Capacity

20 l (5.3 US gal)

Number of Seats

2

Safety Equipment

Riding Modes, Power Modes, Cornering ABS, Ducati Traction Control, Ducati Wheelie Control, Daytime Running Light, Ducati Brake Light

Standard Equipment

Ducati Quick Shift, Ducati Power Launch, Cruise control, Hands-Free, 5" TFT colour display, Ducati Multimedia System, Backlit handlebar switches, Full-LED lighting system, Dynamic turn indicators*

Ready for

Turn-by-Turn navigation system

Warranty

24 months, unlimited mileage

Annual Service

12 months

Valve Clearance Check

60,000 km (37,000 miles)

Oil Service

15,000 km (9,000 miles) / 24 months

CO2 Emissions

60,000 km (37,000 miles)+C43
