A new chapter of motocross.

Ducati transfers its key off-road characteristics to the 250 class, with a Desmo engine that is unique in the segment: a rev limiter at 15,000 rpm ensures more over-rev and less gear changes, a real advantage in racing that makes even more difference with a 250. The Desmo250 MX inherits everything that made the Desmo450 MX unique: precision, reliability, control and advanced electronics, and combines these in an agile and efficient racing bike.

Type

Desmo250, single cylinder, Desmodromic timing system 4 valves DOHC, hydraulic tensioner, semi dry sump, liquid cooled

Displacement

249,7 cc (15,2 cu in)

Bore x Stroke

81 mm x 48,4 mm (3,2 in x 1,9 in)

Compression Ratio

14,5:1

Power

44,5 hp (32,7 kW) @ 12.500 rpm

Torque

28,3 Nm (2,9 kgm, 21 lb ft) @ 8.800 rpm

Fuel Injection

Iniettore Keihin, Corpo farfallato Mikuni Ø 44 mm

Exhaust

Steel muffler with aluminium outer sleeve, steel header with resonator

Gearbox

5 gears with Quick Shift only up

Primary drive

Straight cut gears; Ratio 3.18:1

Ratio

1=32/14, 2=30/16, 3=28/18, 4=26/20, 5=23/21

Final drive

Chain DID DMS 520 , Front sprocket Z13, Rear aluminum sprocket Z51

Clutch

Multiplate clutch with hydraulic control

Frame

Aluminum welded, with cast, forged and extruded parts.

Front suspension

Showa upside down front fork Ø 49 mm fully adjustable .Outer tube with kashima coating

Front Wheel

Central spoked wheel, Takasago Excel rim 1.6'' x 21''

Front Tyre

Pirelli Scorpion XC Mid Soft 80/100-R21

Rear suspension

Showa mono shock, fully adjustable

Rear Wheel

Central spoked wheel, Takasago Excel rim 2.15'' x 19''

Rear Tyre

Pirelli Scorpion MX32 Mid Soft 100/90-R19

Wheel Travel (Front/Rear)

310 mm / 301 mm (12,2 in / 11,9 in)

Front Brake

Galfer Ø 260 mm single disc, Brembo 2-piston floating caliper

Rear Brake

Galfer Ø 240 mm single disc, Brembo 1-piston floating caliper

Instrumentation

Hourmeter

Wet weight no fuel

103 kg (227 lb)

Seat Height

970 mm (38,2 in)

Wheelbase

1.499 mm (59 in)

Rake

26,9°

Trail

116 mm (4,6 in)

Fuel Tank Capacity

7,2 l (1,9 US gal)

Number of Seats

1

Safety Equipment

Riding Modes, Ducati Traction Control (DTC), Engine Brake Control (EBC), Ducati Fall Detection

Standard Equipment

Quick Shift up, Lithium-ion battery, Hourmeter, Power launch

Ready for

Wifi module and X-Link App

Warranty

Ducati Conventional Warranty: 3 months or 20 hours of use

Maintenance service intervals

Oil and oil filter service 15 hours
Piston replacement 45-60 hours
Valve clearance check 45 hours
Main engine service 90-120 hours
