The Ultimate V2 Fighter Formula

New 890 cc V2 engine. The chassis of the Panigale. 175 kg of pure adrenaline, with a high and wide handlebar. No fairings, no filters. The new Streetfighter perfectly embodies the original “provocative spirit”.



Type

Superquadro: 90 ° V2, Desmodromic 4 valves per cylinder, liquid cooled

Displacement

955 cc

Bore x Stroke

100 x 60,8 mm

Compression Ratio

12.5:1

Power

112,3 kW (153 hp) @ 10.750 rpm

Torque

101,4 Nm (74,8 lb-ft) @ 9.000 rpm

Fuel Injection

Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies

Exhaust

2-1-2-1 system, with 2 catalytic converters and 2 lambda probes

Gearbox

6 speed with Ducati Quick Shift (DQS) up/down EVO 2

Primary drive

Straight cut gears; Ratio 1.77:1

Ratio

1=37/15 2=30/16 3=27/18 4=25/20 5=24/22 6=23/24

Final drive

Chain; Front sprocket 15; Rear sprocket 45

Clutch

Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder

Frame

Monocoque Aluminium

Front suspension

Fully adjustable Showa BPF fork. 43 mm chromed inner tubes

Front Wheel

5-spokes light alloy 3.50" x 17"

Front Tyre

Pirelli Diablo Rosso IV 120/70 ZR17M

Rear suspension

Fully adjustable Sachs unit. Aluminium single-sided swingarm

Rear Wheel

5-spokes light alloy 5,50” x 17”

Rear Tyre

Pirelli Diablo Rosso IV 180/60 ZR17M

Wheel Travel (Front/Rear)

120 mm - 130 mm

Front Brake

2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 4-piston calipers with Bosch Cornering ABS EVO. Self bleeding master cylinder

Rear Brake

245 mm disc, 2-piston caliper with Bosch Cornering ABS EVO

Instrumentation

Digital unit with 4,3" TFT colour display

Wet weight no fuel

193 kg

Seat Height

845 mm

Wheelbase

1.465 mm

Rake

24°

Trail

94 mm

Fuel Tank Capacity

17 l

Number of Seats

Dual seat

Safety Equipment

Riding Modes, Power Modes, Bosch Cornering ABS EVO, Ducati Traction Control (DTC) EVO 2, Ducati Wheelie Control (DWC) EVO, Engine Brake Control (EBC) EVO, Auto tyre calibration

Standard Equipment

Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL), Sachs steering damper, Auto-off indicators

Ready for

Ducati Data Analyser+ (DDA+) with GPS module, Ducati Multimedia System (DMS), Ducati LinkApp, Anti-theft

Warranty

24 months unlimited mileage

Maintenance Service Intervals

12,000 km / 12 months

Valve Clearance Check

24,000 km
